No. Item Specification Remark

1 LCD size 7.0 inch(Diagonal)

2 Driver element a-Si TFT active matrix

3 Resolution 800X3(RGB)X480

4 Display mode Normally white, Transmissive

5 Dot pitch 0.0635(W)X0.1905(H) mm

6 Active area 152.4 (W)X91.44 (H) mm

7 Module size 165(W)X104(H)X5.5(D) mm Note 1

8 Surface treatment Anti-Glare

9 Color arrangement RGB-stripe

10 Interface Digital(TTL)

11 Backlight power consumption 2.500W(Typ.) Note 3

12 Panel power consumption 0.825W(Typ.) Note 2

13 Weight 130g (Typ.)

 Download pdf datasheet here
